1x9

Multi-mode 2-fiber

1 / 1
Multi-mode Transceiver


1X9 1.25Gbps MM SC
Product Number Bit Rate 1000
BASE		 Reach Wavelength Voltage Package Temperature
Range		 TX Power RX Sens. Data Sheet
TRM-7100G 1.25 Gb/s SX 300/500 m* 850 nm 3.3 V 1x9 SC    0 ~ 70 °C -4 to -9.5 dBm -18 dBm
TRM-7100AG 1.25 Gb/s SX 300/500 m* 850 nm 3.3 V 1x9 SC -20 ~ 85 °C -4 to -9.5 dBm -18 dBm
TRM-7000G 1.25 Gb/s SX 300/500 m* 850 nm    5 V 1x9 SC    0 ~ 70 °C -4 to -9.5 dBm -18 dBm
TRM-7000AG 1.25 Gb/s SX 300/500 m* 850 nm    5 V 1x9 SC -20 ~ 85 °C -4 to -9.5 dBm -18 dBm
*Note : 300 m for 62.5/125 µm MMF ; 500 m for 50/125 µm MMF


1X9 622 Mbps MM SC
Product Number Bit Rate Reach Wavelength Voltage Package Temperature
Range		 TX Power RX Sens. Data Sheet
TRM-5101G 622 Mb/s 0 ~1000 m 1310 nm 3.3 V 1x9 SC/ST    0 ~ 70 °C -12 to -19 dBm -26 dBm
TRM-5101AG 622 Mb/s 0 ~1000 m 1310 nm 3.3 V 1x9 SC/ST -20 ~ 85 °C -12 to -19 dBm -26 dBm
TRM-5001G 622 Mb/s 0 ~1000 m 1310 nm    5 V 1x9 SC/ST    0 ~ 70 °C -12 to -19 dBm -26 dBm
TRM-5001AG 622 Mb/s 0 ~1000 m 1310 nm    5 V 1x9 SC/ST -20 ~ 85 °C -12 to -19 dBm -26 dBm


1X9 125/155 Mbps MM SC
Product Number Bit Rate Reach Wavelength Voltage Package Temperature
Range		 TX Power RX Sens. Data Sheet
TRM-3102G 125/155 Mb/s 0 ~2000 m 1310 nm 3.3 V 1x9 SC/ST    0 ~ 70 °C -12 to -19 dBm -31 dBm
TRM-3102AG 125/155 Mb/s 0 ~2000 m 1310 nm 3.3 V 1x9 SC/ST -40 ~ 85 °C -12 to -19 dBm -31 dBm
TRM-3002G 125/155 Mb/s 0 ~2000 m 1310 nm    5 V 1x9 SC/ST    0 ~ 70 °C -12 to -19 dBm -31 dBm
TRM-3002AG 125/155 Mb/s 0 ~2000 m 1310 nm    5 V 1x9 SC/ST -40 ~ 85 °C -12 to -19 dBm -31 dBm
