2.5Gb/s 2X5 SFF WDM MM

Product Number	Bit Rate	Reach	TX	RX	Voltage	Package	Temperature Range	TX Power	RX Sens.	Data Sheet
BTRS-9600MG	2.5 Gb/s	300 m	131 0nm	1550 nm	3.3 V	2x5 SC	0 ~ 70°C	0 to -10 dBm	-16 dBm
BTRS-9600AMG	2.5 Gb/s	300 m	1310 nm	1550 nm	3.3 V	2x5 SC	-40 ~ 85°C	0 to -10 dBm	-16 dBm
BTRS-9700MG	2.5 Gb/s	300 m	1550 nm	1310 nm	3.3 V	2x5 SC	0 ~ 70°C	0 to -10 dBm	-16 dBm
BTRS-9700AMG	2.5 Gb/s	300 m	1550 nm	1310 nm	3.3 V	2x5 SC	-40 ~ 85°C	0 to -10 dBm	-16 dBm

Gigabit 2X5 SFF WDM MM

Product Number	Bit Rate	Reach	TX	RX	Voltage	Package	Temperature Range	TX Power	RX Sens.	Data Sheet
BTRS-7600MG	1.25 Gb/s	500 m	1310 nm	1550 nm	3.3V	2x5 SC	0 ~ 70°C	-4 to -10 dBm	-17 dBm
BTRS-7600AMG	1.25 Gb/s	500 m	1310 nm	1550 nm	3.3V	2x5 SC	-40 ~ 85°C	-4 to -10 dBm	-17 dBm
BTRS-7700MG	1.25 Gb/s	500 m	1550 nm	1310 nm	3.3V	2x5 SC	0 ~ 70°C	-4 to -10 dBm	-17 dBm
BTRS-7700AMG	1.25 Gb/s	500 m	1550 nm	1310 nm	3.3V	2x5 SC	-40 ~ 85°C	-4 to -10 dBm	-17 dBm

622Mb/s 2X5 SFF WDM MM

Product Number	Bit Rate	Reach	TX	RX	Voltage	Package	Temperature Range	TX Power	RX Sens.	Data Sheet
BTRS-5601MG	622 Mb/s	0 ~ 1000 m	1310 nm	1550 nm	3.3 V	2x5 SC	0 ~ 70°C	-8 to -15 dBm	-26 dBm
BTRS-5601AMG	622 Mb/s	0 ~ 1000 m	1310 nm	1550 nm	3.3 V	2x5 SC	-40 ~ 85°C	-8 to -15 dBm	-26 dBm
BTRS-5701MG	622 Mb/s	0 ~ 1000 m	1550 nm	1310 nm	3.3 V	2x5 SC	0 ~ 70°C	-8 to -15 dBm	-26 dBm
BTRS-5701AMG	622 Mb/s	0 ~ 1000 m	1550 nm	1310 nm	3.3 V	2x5 SC	-40 ~ 85°C	-8 to -15 dBm	-26 dBm

155Mb/s 2X5 SFF WDM MM

Product Number	Bit Rate	Reach	TX	RX	Voltage	Package	Temperature Range	TX Power	RX Sens.	Data Sheet
BTRS-3602MG	125 Mb/s	0 ~ 2000 m	1310 nm	1550 nm	3.3V	2x5 SC	0 ~ 70°C	-8 to -15 dBm	-30 dBm
BTRS-3602AMG	125 Mb/s	0 ~ 2000 m	1310 nm	1550 nm	3.3V	2x5 SC	-40 ~ 85°C	-8 to -15 dBm	-30 dBm
BTRS-3702MG	125 Mb/s	0 ~ 2000 m	1550 nm	1310 nm	3.3V	2x5 SC	0 ~ 70°C	-8 to -15 dBm	-30 dBm
BTRS-3702AMG	125 Mb/s	0 ~ 2000 m	1550 nm	1310 nm	3.3V	2x5 SC	-40 ~ 85°C	-8 to -15 dBm	-30 dBm
