1G/2.5G/3.2Gbps

Multi-rate (3.2Gb/s) SFP 1-fiber

1 / 1
3.2Gb/s Multi-rate SFP
Product Number Bit Rate Reach TX RX Package Temperature
Range		 TX Power RX Sens. Data
Sheet
SPB-9605RG Multi-rate*    5 km 1310 nm 1550 nm SC/LC SFP    0 ~ 70°C -3 to -10 dBm -18 dBm
SPB-9605BRG Multi-rate*    5 km 1310 nm 1550 nm SC/LC SFP -10 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9605ARG Multi-rate*    5 km 1310 nm 1550 nm SC/LC SFP -40 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9705RG Multi-rate*    5 km 1550 nm DFB 1310 nm SC/LC SFP    0 ~ 70°C -3 to -10 dBm -18 dBm
SPB-9705BRG Multi-rate*    5 km 1550 nm DFB 1310 nm SC/LC SFP -10 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9705ARG Multi-rate*    5 km 1550 nm DFB 1310 nm SC/LC SFP -40 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9620RG Multi-rate*   20 km 1310 nm DFB 1550 nm SC/LC SFP    0 ~ 70°C  0 to   -5 dBm -18 dBm
SPB-9620BRG Multi-rate*   20 km 1310 nm DFB 1550 nm SC/LC SFP -10 ~ 85°C  0 to   -5 dBm -18 dBm
SPB-9620ARG Multi-rate*   20 km 1310 nm DFB 1550 nm SC/LC SFP -40 ~ 85°C  0 to   -5 dBm -18 dBm
SPB-9720RG Multi-rate*   20 km 1550 nm DFB 1310 nm SC/LC SFP    0 ~ 70°C  0 to   -5 dBm -18 dBm
SPB-9720BRG Multi-rate*   20 km 1550 nm DFB 1310 nm SC/LC SFP -10 ~ 85°C  0 to   -5 dBm -18 dBm
SPB-9720ARG Multi-rate*   20 km 1550 nm DFB 1310 nm SC/LC SFP -40 ~ 85°C  0 to   -5 dBm -18 dBm
SPB-9640RG Multi-rate*   40 km 1310 nm DFB 1550 nm SC/LC SFP    0 ~ 70°C  3 to   -2 dBm -20 dBm
SPB-9640BRG Multi-rate*   40 km 1310 nm DFB 1550 nm SC/LC SFP -10 ~ 85°C  3 to   -2 dBm -20 dBm
SPB-9640ARG Multi-rate*   40 km 1310 nm DFB 1550 nm SC/LC SFP -40 ~ 85°C  3 to   -2 dBm -20 dBm
SPB-9740RG Multi-rate*   40 km 1550 nm DFB 1310 nm SC/LC SFP    0 ~ 70°C  3 to   -2 dBm -20 dBm
SPB-9740BRG Multi-rate*   40 km 1550 nm DFB 1310 nm SC/LC SFP -10 ~ 85°C  3 to   -2 dBm -20 dBm
SPB-9740ARG Multi-rate*   40 km 1550 nm DFB 1310 nm SC/LC SFP -40 ~ 85°C  3 to   -2 dBm -20 dBm
SPB-9780R-1510G Multi-rate*   80 km 1510 nm DFB 1590 nm SC/LC SFP    0 ~ 70°C  3 to   -2 dBm -28 dBm
SPB-9780BR-1510G Multi-rate*   80 km 1510 nm DFB 1590 nm SC/LC SFP -10 ~ 85°C  3 to   -2 dBm -28 dBm
SPB-9780AR-1510G Multi-rate*   80 km 1510 nm DFB 1590 nm SC/LC SFP -40 ~ 85°C  3 to   -2 dBm -28 dBm
SPB-9780R-1590G Multi-rate*   80 km 1590 nm DFB 1510 nm SC/LC SFP    0 ~ 70°C  3 to   -2 dBm -28 dBm
SPB-9780BR-1590G Multi-rate*   80 km 1590 nm DFB 1510 nm SC/LC SFP -10 ~ 85°C  3 to   -2 dBm -28 dBm
SPB-9780AR-1590G Multi-rate*   80 km 1590 nm DFB 1510 nm SC/LC SFP -40 ~ 85°C  3 to   -2 dBm -28 dBm
SPB-97120R-1510G Multi-rate* 120 km 1510 nm DFB 1590 nm SC/LC SFP    0 ~ 70°C  4 to    0 dBm -28 dBm
SPB-97120R-1590G Multi-rate* 120 km 1590 nm DFB 1510 nm SC/LC SFP    0 ~ 70°C  4 to    0 dBm -28 dBm
SPB-9605RWG Multi-rate*     5 km 1310 nm 1550 nm SC/LC SFP with DMI    0 ~ 70°C -3 to -10 dBm -18 dBm
SPB-9605BRWG Multi-rate*     5 km 1310 nm 1550 nm SC/LC SFP with DMI -10 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9605ARWG Multi-rate*     5 km 1310 nm 1550 nm SC/LC SFP with DMI -40 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9705RWG Multi-rate*     5 km 1550 nm DFB 1310 nm SC/LC SFP with DMI    0 ~ 70°C -3 to -10dBm -18 dBm
SPB-9705BRWG Multi-rate*     5 km 1550 nm DFB 1310 nm SC/LC SFP with DMI -10 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9705ARWG Multi-rate*     5 km 1550 nm DFB 1310 nm SC/LC SFP with DMI -40 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9620RWG Multi-rate*   20 km 1310 nm DFB 1550 nm SC/LC SFP with DMI    0 ~ 70°C  0 to   -5 dBm -18 dBm
SPB-9620BRWG Multi-rate*   20 km 1310 nm DFB 1550 nm SC/LC SFP with DMI -10 ~ 85°C  0 to   -5 dBm -18 dBm
SPB-9620ARWG Multi-rate*   20 km 1310 nm DFB 1550 nm SC/LC SFP with DMI -40 ~ 85°C  0 to   -5 dBm -18 dBm
SPB-9720RWG Multi-rate*   20 km 1550 nm DFB 1310 nm SC/LC SFP with DMI    0 ~ 70°C  0 to   -5 dBm -18 dBm
SPB-9720BRWG Multi-rate*   20 km 1550 nm DFB 1310 nm SC/LC SFP with DMI -10 ~ 85°C  0 to   -5 dBm -18 dBm
SPB-9720ARWG Multi-rate*   20 km 1550 nm DFB 1310 nm SC/LC SFP with DMI -40 ~ 85°C  0 to   -5 dBm -18 dBm
SPB-9740RWG Multi-rate*   40 km 1550 nm DFB 1310 nm SC/LC SFP with DMI    0 ~ 70°C  3 to   -2 dBm -20 dBm
SPB-9740BRWG Multi-rate*   40 km 1550 nm DFB 1310 nm SC/LC SFP with DMI -10 ~ 85°C  3 to   -2 dBm -20 dBm
SPB-9740ARWG Multi-rate*   40 km 1550 nm DFB 1310 nm SC/LC SFP with DMI -40 ~ 85°C  3 to   -2 dBm -20 dBm
SPB-9640RWG Multi-rate*   40 km 1310 nm DFB 1550 nm SC/LC SFP with DMI    0 ~ 70°C  3 to   -2 dBm -20 dBm
SPB-9640BRWG Multi-rate*   40 km 1310 nm DFB 1550 nm SC/LC SFP with DMI -10 ~ 85°C  3 to   -2 dBm -20 dBm
SPB-9640ARWG Multi-rate*   40 km 1310 nm DFB 1550 nm SC/LC SFP with DMI -40 ~ 85°C  3 to   -2 dBm -20 dBm
SPB-9780RW-1510G Multi-rate*   80 km 1510 nm DFB 1550 nm SC/LC SFP with DMI    0 ~ 70°C  3 to   -2 dBm -28 dBm
SPB-9780BRW-1510G Multi-rate*   80 km 1510 nm DFB 1590 nm SC/LC SFP with DMI -10 ~ 85°C  3 to   -2 dBm -28 dBm
SPB-9780ARW-1510G Multi-rate*   80 km 1510 nm DFB 1590 nm SC/LC SFP with DMI -40 ~ 85°C  3 to   -2 dBm -28 dBm
SPB-9780RW-1590G Multi-rate*   80 km 1590 nm DFB 1510 nm SC/LC SFP with DMI    0 ~ 70°C  3 to   -2 dBm -28 dBm
SPB-9780BRW-1590G Multi-rate*   80 km 1590 nm DFB 1510 nm SC/LC SFP with DMI -10 ~ 85°C  3 to   -2 dBm -28 dBm
SPB-9780ARW-1590G Multi-rate*   80 km 1590 nm DFB 1510 nm SC/LC SFP with DMI -40 ~ 85°C  3 to   -2 dBm -28 dBm
SPB-97120RW-1510G Multi-rate* 120 km 1510 nm DFB 1590 nm SC/LC SFP with DMI    0 ~ 70°C  4 to    0 dBm -28 dBm
SPB-97120RW-1590G Multi-rate* 120 km 1590 nm DFB 1510 nm SC/LC SFP with DMI    0 ~ 70°C  4 to    0 dBm -28 dBm
*3.185Gb/s,3.125Gb/s, 2.67Gb/s / OC-48 / 2X FC / GbE / 1X FC / OC-12 / OC-3


3.2Gb/s Multi-rate SFP (1310nm/1490nm)
Product Number Bit Rate Reach TX RX Package Tempearture
Range		 TX Power RX Sens. Data
Sheet
SPB-9805RG Multi-rate*   5 km 1310 nm 1490 nm SC/LC SFP    0 ~ 70°C -3 to -10 dBm -18 dBm
SPB-9805BRG Multi-rate*   5 km 1310 nm 1490 nm SC/LC SFP -10 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9805ARG Multi-rate*   5 km 1310 nm 1490 nm SC/LC SFP -40 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9905RG Multi-rate*   5 km 1490 nm DFB 1310 nm SC/LC SFP    0 ~ 70°C -3 to -10 dBm -18 dBm
SPB-9905BRG Multi-rate*   5 km 1490 nm DFB 1310 nm SC/LC SFP -10 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9905ARG Multi-rate*   5 km 1490 nm DFB 1310 nm SC/LC SFP -40 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9820RG Multi-rate* 20 km 1310 nm DFB 1490 nm SC/LC SFP    0 ~ 70°C   0 to  -5 dBm -18 dBm
SPB-9820BRG Multi-rate* 20 km 1310 nm DFB 1490 nm SC/LC SFP -10 ~ 85°C   0 to  -5 dBm -18 dBm
SPB-9820ARG Multi-rate* 20 km 1310 nm DFB 1490 nm SC/LC SFP -40 ~ 85°C   0 to  -5 dBm -18 dBm
SPB-9920RG Multi-rate* 20 km 1490 nm DFB 1310 nm SC/LC SFP    0 ~ 70°C   0 to  -5 dBm -18 dBm
SPB-9920BRG Multi-rate* 20 km 1490 nm DFB 1310 nm SC/LC SFP -10 ~ 85°C   0 to  -5 dBm -18 dBm
SPB-9920ARG Multi-rate* 20 km 1490 nm DFB 1310 nm SC/LC SFP -40 ~ 85°C   0 to  -5 dBm -18 dBm
SPB-9840RG Multi-rate* 40 km 1310 nm DFB 1490 nm SC/LC SFP    0 ~ 70°C   3 to  -2 dBm -20 dBm
SPB-9840BRG Multi-rate* 40 km 1310 nm DFB 1490 nm SC/LC SFP -10 ~ 85°C   3 to  -2 dBm -20 dBm
SPB-9840ARG Multi-rate* 40 km 1310 nm DFB 1490 nm SC/LC SFP -40 ~ 85°C   3 to  -2 dBm -20 dBm
SPB-9940RG Multi-rate* 40 km 1490 nm DFB 1310 nm SC/LC SFP    0 ~ 70°C   3 to  -2 dBm -20 dBm
SPB-9940BRG Multi-rate* 40 km 1490 nm DFB 1310 nm SC/LC SFP -10 ~ 85°C   3 to  -2 dBm -20 dBm
SPB-9940ARG Multi-rate* 40 km 1490 nm DFB 1310 nm SC/LC SFP -40 ~ 85°C   3 to  -2 dBm -20 dBm
SPB-9805RWG Multi-rate*   5 km 1310 nm 1490 nm SC/LC SFP with DMI    0 ~ 70°C -3 to -10 dBm -18 dBm
SPB-9805BRWG Multi-rate*   5 km 1310 nm 1490 nm SC/LC SFP with DMI -10 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9805ARWG Multi-rate*   5 km 1310 nm 1490 nm SC/LC SFP with DMI -40 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9905RWG Multi-rate*   5 km 1490 nm DFB 1310 nm SC/LC SFP with DMI    0 ~ 70°C -3 to -10 dBm -18 dBm
SPB-9905BRWG Multi-rate*   5 km 1490 nm DFB 1310 nm SC/LC SFP with DMI -10 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9905ARWG Multi-rate*   5 km 1490 nm DFB 1310 nm SC/LC SFP with DMI -40 ~ 85°C -3 to -10 dBm -18 dBm
SPB-9820RWG Multi-rate* 20 km 1310 nm DFB 1490 nm SC/LC SFP with DMI    0 ~ 70°C   0 to  -5 dBm -18 dBm
SPB-9820BRWG Multi-rate* 20 km 1310 nm DFB 1490 nm SC/LC SFP with DMI -10 ~ 85°C   0 to  -5 dBm -18 dBm
SPB-9820ARWG Multi-rate* 20 km 1310 nm DFB 1490 nm SC/LC SFP with DMI -40 ~ 85°C   0 to  -5 dBm -18 dBm
SPB-9920RWG Multi-rate* 20 km 1490 nm DFB 1310 nm SC/LC SFP with DMI    0 ~ 70°C   0 to  -5 dBm -18 dBm
SPB-9920BRWG Multi-rate* 20 km 1490 nm DFB 1310 nm SC/LC SFP with DMI -10 ~ 85°C   0 to  -5 dBm -18 dBm
SPB-9920ARWG Multi-rate* 20 km 1490 nm DFB 1310nm SC/LC SFP with DMI -40 ~ 85°C   0 to  -5 dBm -18 dBm
SPB-9840RWG Multi-rate* 40 km 1310 nm DFB 1490 nm SC/LC SFP with DMI    0 ~ 70°C   3 to  -2 dBm -20 dBm
SPB-9840BRWG Multi-rate* 40 km 1310 nm DFB 1490 nm SC/LC SFP with DMI -10 ~ 85°C   3 to  -2 dBm -20 dBm
SPB-9840ARWG Multi-rate* 40 km 1310 nm DFB 1490 nm SC/LC SFP with DMI -40 ~ 85°C   3 to  -2 dBm -20 dBm
SPB-9940RWG Multi-rate* 40 km 1490 nm DFB 1310 nm SC/LC SFP with DMI    0 ~ 70°C   3 to  -2 dBm -20 dBm
SPB-9940BRWG Multi-rate* 40 km 1490 nm DFB 1310 nm SC/LC SFP with DMI -10 ~ 85°C   3 to  -2 dBm -20 dBm
SPB-9940ARWG Multi-rate* 40 km 1490 nm DFB 1310 nm SC/LC SFP with DMI -40 ~ 85°C   3 to  -2 dBm -20 dBm
*3.185Gb/s,3.125Gb/s, 2.67Gb/s / OC-48 / 2X FC / GbE / 1X FC / OC-12 / OC-3
