| Product Number | Bit Rate | SONET /SDH |
Power Budget | Spacing / Wavelength | Package | Temperature Range |
TX Power | RX Sens. | Data Sheet |
| SPS-5380W-DXXG | 622 Mb/s | LR-2/L-4.2 | >29 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -29 dBm |  |
| SPS-5380BW-DXXG | 622 Mb/s | LR-2/L-4.2 | >29 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -29 dBm | |
| SPS-5380AW-DXXG | 622 Mb/s | LR-2/L-4.2 | >29 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -29 dBm | |
| SPS-53120W-DXXG | 622 Mb/s | >34 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120BW-DXXG | 622 Mb/s | >34 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53120AW-DXXG | 622 Mb/s | >34 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 0 dBm | -34 dBm | |
|
| SPS-53160W-DXXG | 622 Mb/s | >39 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 5 to 2 dBm | -37 dBm | |
|
| SPS-53160BW-DXXG | 622 Mb/s | >39 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 5 to 2 dBm | -37 dBm | |
|
| SPS-53160AW-DXXG | 622 Mb/s | >39 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 5 to 2 dBm | -37 dBm | |
|
| SPS-53200W-DXXG | 622 Mb/s | >42 dB | 100GHz with DWDM | SFP with DMI | 0 ~ 70°C | 7 to 4 dBm | -38 dBm | |
|
| SPS-53200BW-DXXG | 622 Mb/s | >42 dB | 100GHz with DWDM | SFP with DMI | -10 ~ 85°C | 7 to 4 dBm | -38 dBm | |
|
| SPS-53200AW-DXXG | 622 Mb/s | >42 dB | 100GHz with DWDM | SFP with DMI | -40 ~ 85°C | 7 to 4 dBm | -38 dBm | |
PRODUCTS
100Mbps to 622Mbps
622 Mb/s DWDM
