PRODUCTS
CWDM/DWDM

SFP CWDM

32Gb/s FC CWDM SFP28 SM LC
Product Number FC 32G FC Power Budget Wavelength Package Temperature
Range
Data
Sheet
SPS-2502FW-CXX0G 32G/16G/8 G 3200-SM >   7 dB CWDM* SFP28 with DMI    0 ~ 70°C
SPS-2510FW-CXX0G 32G/16G/8 G 3200-SM > 14 dB CWDM* SFP28 with DMI    0 ~ 70°C
SPS-2520FW-CXX0G 32G/16G/8 G 3200-SM > 17 dB CWDM* SFP28 with DMI    0 ~ 70°C
SPS-2530FW-CXX0G 32G/16G/8 G 3200-SM > 21 dB CWDM* SFP28 with DMI    0 ~ 70°C
* 4-Wavelength from 1270 nm to 1330 nm, each step 20 nm


25Gb/s CWDM SFP28 SM LC
Product Number Bit Rate 25GBASE / CPRI Power Budget Wavelength Package Temperature
Range
Data
Sheet
SPS-2502W-CXX0G Up to 25.78 Gb/s LR / Option 10 >   8.3 dB CWDM* SFP28 with DMI    0 ~ 70°C
SPS-2502BW-CXX0G Up to 25.78 Gb/s LR / Option 10 >   8.3 dB CWDM* SFP28 with DMI -10 ~ 85°C
SPS-2502AW-CXX0G Up to 25.78 Gb/s LR / Option 10 >   8.3 dB CWDM* SFP28 with DMI -40 ~ 85°C
SPS-2510W-CXX0G Up to 25.78 Gb/s LR / Option 10 > 14.3 dB CWDM* SFP28 with DMI    0 ~ 70°C
SPS-2510BW-CXX0G Up to 25.78 Gb/s LR / Option 10 > 14.3 dB CWDM* SFP28 with DMI -10 ~ 85°C
SPS-2510AW-CXX0G Up to 25.78 Gb/s LR / Option 10 > 14.3 dB CWDM* SFP28 with DMI -40 ~ 85°C
SPS-2520W-CXX0G Up to 25.78 Gb/s LR / Option 10 > 17.3 dB CWDM** SFP28 with DMI    0 ~ 70°C
SPS-2520BW-CXX0G Up to 25.78 Gb/s LR / Option 10 > 17.3 dB CWDM** SFP28 with DMI -10 ~ 85°C
SPS-2520AW-CXX0G Up to 25.78 Gb/s LR / Option 10 > 17.3 dB CWDM** SFP28 with DMI -40 ~ 85°C
SPS-2530W-CXX0G Up to 25.78 Gb/s LR / Option 10 > 21.4 dB CWDM** SFP28 with DMI    0 ~ 70°C
SPS-2530BW-CXX0G Up to 25.78 Gb/s LR / Option 10 > 21.4 dB CWDM** SFP28 with DMI -10 ~ 85°C
SPS-2530AW-CXX0G Up to 25.78 Gb/s LR / Option 10 > 21.4 dB CWDM** SFP28 with DMI -40 ~ 85°C
  6-Wavelength from 1270 nm to 1370 nm, each step 20 nm, for SPS-2502(B)(A)W-CXX0G, SPS-2510(B)(A)W-CXX0G
** 4-Wavelength from 1270 nm to 1330 nm, each step 20 nm, for SPS-2520(B)(A)W-CXX0G, SPS-2530(B)(A)W-CXX0G


16GFC SFP+ SM LC CWDM
Product Number FC 16G FC Reach Wavelength Package Temperature
Range
Data
Sheet
SPS-6310W-CXX0G 16/8/4 G 1600-SM 10 km 1270~1330 nm SFP+ with DMI    0 ~ 70°C
SPS-6311W-CXX0G 16/8/4 G 1600-SM 10 km 1470~1610 nm SFP+ with DMI    0 ~ 70°C
SPS-6341W-CXX0G* 16/8/4 G 1600-SM 40 km 1470~1610 nm SFP+ with DMI    0 ~ 70°C
*RX with rate selected CDR


10Gb/s CWDM SFP+ SM LC
Product Number Bit Rate 10G BASE Reach Wavelength Package Temperature
Range
Data
Sheet
SPS-2310W-CXX0G 10.3 Gb/s LR/LW 10 km CWDM* SFP+ with DMI    0 ~ 70°C
SPS-2310BW-CXX0G 10.3 Gb/s LR/LW 10 km CWDM* SFP+ with DMI -10 ~ 85°C
SPS-2310AW-CXX0G 10.3 Gb/s LR/LW 10 km CWDM* SFP+ with DMI -40 ~ 85°C
SPS-2340W-CXX0G 10.3 Gb/s   40 km CWDM** SFP+ with DMI    0 ~ 70°C
SPS-2340BW-CXX0G 10.3 Gb/s   40 km CWDM** SFP+ with DMI -10 ~ 85°C
SPS-2340AW-CXX0G 10.3 Gb/s   40 km CWDM** SFP+ with DMI -40 ~ 85°C
SPS-2370W-CXX0G 10.3 Gb/s   70 km CWDM*** SFP+ with DMI    0 ~ 70°C
SPS-2370BW-CXX0G 10.3 Gb/s   70 km CWDM*** SFP+ with DMI -10 ~ 85°C
SPS-2370AW-CXX0G 10.3 Gb/s   70 km CWDM*** SFP+ with DMI -40 ~ 85°C
SPS-2341W-CXX0G 10.3 Gb/s ER/EW 40 km CWDM**** SFP+ with DMI    0 ~ 70°C
SPS-2341BW-CXX0G 10.3 Gb/s ER/EW 40 km CWDM**** SFP+ with DMI  -5 ~  85°C
SPS-2371W-CXX0G 10.3 Gb/s ER/EW 70 km CWDM**** SFP+ with DMI    0 ~ 70°C
SPS-2371BW-CXX0G 10.3 Gb/s ER/EW 70 km CWDM**** SFP+ with DMI  -5 ~  85°C
SPS-2341MW-CXX0G 9.95 ~11.1 Gb/s Multirate***** 40 km CWDM**** SFP+ with DMI   0 ~  70°C
*   18-Wavelength from 1270 nm to 1610 nm, each step 20 nm
**   6-Wavelength from 1270 nm to 1370 nm, each step 20 nm
***  4-Wavelength from 1270 nm to 1330 nm, each step 20 nm
**** 8-Wavelength from 1470 nm to 1610 nm, each step 20 nm
*****multirate for SONET OC-192 / SDH STM-64, 10GBASE, 10G Fibre Channel, ITU-T G.709, 10GBASE + FEC


8.5Gb/s CWDM SFP+ SM LC
Product Number Bit Rate FC-PI Reach Wavelength Package Temperature
Range
Data Sheet
SPS-4310-CXX0G 8/4/2 Gb/s FC-PI-4 10 km CWDM* LC SFP+ 0 ~ 70°C
SPS-4340-CXX0G 8/4/2 Gb/s FC-PI-4 40 km CWDM** LC SFP+ 0 ~ 70°C
SPS-4310W-CXX0G 8/4/2 Gb/s FC-PI-4 10 km CWDM* SFP+ with DMI 0 ~ 70°C
SPS-4340W-CXX0G 8/4/2 Gb/s FC-PI-4 40 km CWDM** SFP+ with DMI 0 ~ 70°C
SPS-4341W-CXX0G 8/4/2 Gb/s FC-PI-4 40 km CWDM*** SFP+ with DMI 0 ~ 70°C
SPS-4371W-CXX0G 8/4/2 Gb/s FC-PI-4 70 km CWDM*** SFP+ with DMI 0 ~ 70°C
*   18-Wavelength from 1270 nm to 1610 nm, each step 20 nm
**   8-Wavelength from 1270 nm to 1370 nm, each step 20 nm
***  8-Wavelength from 1470 nm to 1610 nm, each step 20 nm



6Gb/s CWDM SFP+ SM LC
Product Number Bit Rate Reach Wavelength Package Temperature
Range
Data
Sheet
SPS-4310RW-CXX0G 1 ~ 6.25 Gb/s 10 km CWDM* SFP+ with DMI    0 ~ 70°C
SPS-4340RW-CXX0G 1 ~ 6.25 Gb/s 40 km CWDM* SFP+ with DMI    0 ~ 70°C
SPS-4371RW-CXX0G 1 ~ 6.25 Gb/s 70 km CWDM** SFP+ with DMI    0 ~ 70°C
*  18 Wavelength from 1270 nm to 1610 nm, each step 20 nm
**  8 Wavelength from 1470 nm to 1610 nm, each step 20 nm


4.25Gb/s CWDM SFP SM LC
Product Number Bit Rate FC-PI Power
Budget
Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-8340-CXX0G 4/2/1 Gb/s 400/200/100 >18 dB CWDM* LC SFP   0 ~ 70°C  4 to 0 dBm -18 dBm
SPS-8360-CXX0G 4/2/1 Gb/s 400/200/100 >26 dB CWDM* LC SFP   0 ~ 70°C  4 to 0 dBm -26 dBm
SPS-8380-CXX0G 4/2/1 Gb/s 400/200/100 >28 dB CWDM* LC SFP   0 ~ 70°C  5 to 1 dBm -27 dBm
SPS-83100-CXX0G 4/2/1 Gb/s 400/200/100 >30 dB CWDM* LC SFP   0 ~ 70°C  6 to 3 dBm -27 dBm
SPS-8340W-CXX0G 4/2/1 Gb/s 400/200/100 >18 dB CWDM* LC SFP with DMI   0 ~ 70°C  4 to 0 dBm -18 dBm
SPS-8360W-CXX0G 4/2/1 Gb/s 400/200/100 >26 dB CWDM* LC SFP with DMI   0 ~ 70°C  4 to 0 dBm -26 dBm
SPS-8380W-CXX0G 4/2/1 Gb/s 400/200/100 >28 dB CWDM* LC SFP with DMI   0 ~ 70°C  5 to 1 dBm -27 dBm
SPS-83100W-CXX0G 4/2/1 Gb/s 400/200/100 >30 dB CWDM* LC SFP with DMI   0 ~ 70°C  6 to 3 dBm -27 dBm
*18 Wavelength : from 1270 nm to 1610 nm , each step 20 nm


3.2Gb/s Multi-rate CWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power Budget Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-9340R-CXX0G Multi-rate*   >18 dB CWDM** LC SFP    0 ~ 70°C 3 to -2 dBm -20 dBm
SPS-9340BR-CXX0G Multi-rate*   >18 dB CWDM** LC SFP   -5 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9340AR-CXX0G Multi-rate*   >18 dB CWDM** LC SFP -40 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9380R-CXX0G Multi-rate*   >28 dB CWDM** LC SFP    0 ~ 70°C 5 to 0 dBm -28 dBm
SPS-9380BR-CXX0G Multi-rate*   >28 dB CWDM** LC SFP   -5 ~ 85°C 5 to 0 dBm -28 dBm
SPS-9380AR-CXX0G Multi-rate*   >28 dB CWDM** LC SFP -40 ~ 85°C 5 to 0 dBm -28 dBm
SPS-93100R-CXX0G Multi-rate*   >31 dB CWDM** LC SFP    0 ~ 70°C 6 to 3 dBm -28 dBm
SPS-93100BR-CXX0G Multi-rate*   >31 dB CWDM** LC SFP   -5 ~ 85°C 6 to 3 dBm -28 dBm
SPS-93100AR-CXX0G Multi-rate*   >31 dB CWDM** LC SFP -40 ~ 85°C 6 to 3 dBm -28 dBm
SPS-9340RW-CXX0G Multi-rate*   >18 dB CWDM** LC SFP with DMI    0 ~ 70°C 3 to -2 dBm -20 dBm
SPS-9340BRW-CXX0G Multi-rate*   >18 dB CWDM** LC SFP with DMI   -5 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9340ARW-CXX0G Multi-rate*   >18 dB CWDM** LC SFP with DMI -40 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9380RW-CXX0G Multi-rate*   >28 dB CWDM** LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -28 dBm
SPS-9380BRW-CXX0G Multi-rate*   >28 dB CWDM** LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -28 dBm
SPS-9380ARW-CXX0G Multi-rate*   >28 dB CWDM** LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -28 dBm
SPS-93100RW-CXX0G Multi-rate*   >31 dB CWDM** LC SFP with DMI    0 ~ 70°C 6 to 3 dBm -28 dBm
SPS-93100BRW-CXX0G Multi-rate*   >31 dB CWDM** LC SFP with DMI   -5 ~ 85°C 6 to 3 dBm -28 dBm
SPS-93100ARW-CXX0G Multi-rate*   >31 dB CWDM** LC SFP with DMI -40 ~ 85°C 6 to 3 dBm -28 dBm
*  3.185Gb/s,3.125Gb/s, 2.67Gb/s / OC-48 / 2X FC / GbE / 1X FC / OC-12 / OC-3
**18 Wavelength : from 1270 nm to 1610 nm , each step 20 nm


2.67Gb/s Multi-rate CWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power Budget Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-9340M-CXX0G Multi-rate* IR-2/S-16.2 >18 dB CWDM** LC SFP    0 ~ 70°C 3 to -2 dBm -20d Bm
SPS-9340BM-CXX0G Multi-rate* IR-2/S-16.2 >18 dB CWDM** LC SFP   -5 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9340AM-CXX0G Multi-rate* IR-2/S-16.2 >18 dB CWDM** LC SFP -40 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9380M-CXX0G Multi-rate* LR-2/L-16.2 >28 dB CWDM** LC SFP    0 ~ 70°C 5 to 0 dBm -28 dBm
SPS-9380BM-CXX0G Multi-rate* LR-2/L-16.2 >28 dB CWDM** LC SFP   -5 ~ 85°C 5 to 0 dBm -28 dBm
SPS-9380AM-CXX0G Multi-rate* LR-2/L-16.2 >28 dB CWDM** LC SFP -40 ~ 85°C 5 to 0 dBm -28 dBm
SPS-93100M-CXX0G Multi-rate* LR-2/L-16.2 >31 dB CWDM** LC SFP    0 ~ 70°C 5 to 1 dBm -30 dBm
SPS-93100BM-CXX0G Multi-rate* LR-2/L-16.2 >31 dB CWDM** LC SFP   -5 ~ 85°C 5 to 1 dBm -30 dBm
SPS-93100AM-CXX0G Multi-rate* LR-2/L-16.2 >31 dB CWDM** LC SFP -40 ~ 85°C 5 to 1 dBm -30 dBm
SPS-93120M-CXX0G Multi-rate* LR-2/L-16.2 >33 dB CWDM** LC SFP    0 ~ 70°C 6 to 3 dBm -30 dBm
SPS-93120BM-CXX0G Multi-rate* LR-2/L-16.2 >33 dB CWDM** LC SFP   -5 ~ 85°C 6 to 3 dBm -30dBm
SPS-93120AM-CXX0G Multi-rate* LR-2/L-16.2 >33 dB CWDM** LC SFP -40 ~ 85°C 6 to 3 dBm -30 dBm
SPS-9340MW-CXX0G Multi-rate* IR-2/S-16.2 >18 dB CWDM** LC SFP with DMI    0 ~ 70°C 3 to -2 dBm -20 dBm
SPS-9340BMW-CXX0G Multi-rate* IR-2/S-16.2 >18 dB CWDM** LC SFP with DMI   -5 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9340AMW-CXX0G Multi-rate* IR-2/S-16.2 >18 dB CWDM** LC SFP with DMI -40 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9380MW-CXX0G Multi-rate* LR-2/L-16.2 >28 dB CWDM** LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -28 dBm
SPS-9380BMW-CXX0G Multi-rate* LR-2/L-16.2 >28 dB CWDM** LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -28 dBm
SPS-9380AMW-CXX0G Multi-rate* LR-2/L-16.2 >28 dB CWDM** LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -28 dBm
SPS-93100MW-CXX0G Multi-rate* LR-2/L-16.2 >31 dB CWDM** LC SFP with DMI    0 ~ 70°C 5 to 1 dBm -30 dBm
SPS-93100BMW-CXX0G Multi-rate* LR-2/L-16.2 >31 dB CWDM** LC SFP with DMI   -5 ~ 85°C 5 to 1 dBm -30 dBm
SPS-93100AMW-CXX0G Multi-rate* LR-2/L-16.2 >31 dB CWDM** LC SFP with DMI -40 ~ 85°C 5 to 1 dBm -30 dBm
SPS-93120MW-CXX0G Multi-rate* LR-2/L-16.2 >33 dB CWDM** LC SFP with DMI    0 ~ 70°C 6 to 3 dBm -30 dBm
SPS-93120BMW-CXX0G Multi-rate* LR-2/L-16.2 >33 dB CWDM** LC SFP with DMI   -5 ~ 85°C 6 to 3 dBm -30 dBm
SPS-93120AMW-CXX0G Multi-rate* LR-2/L-16.2 >33 dB CWDM** LC SFP with DMI -40 ~ 85°C 6 to 3 dBm -30d Bm
*  2.67Gb/s / OC-48 / 2X FC / GbE / 1X FC / OC-12 / OC-3 / FE
**18 Wavelength : from 1270 nm to 1610 nm , each step 20 nm


2.488Gb/s CWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power Budget Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-9340-CXX0G 2.488 Gb/s IR-2/S-16.2 >18 dB CWDM* LC SFP    0 ~ 70°C 3 to -2 dBm -20 dBm
SPS-9340B-CXX0G 2.488 Gb/s IR-2/S-16.2 >18 dB CWDM* LC SFP   -5 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9340A-CXX0G 2.488 Gb/s IR-2/S-16.2 >18 dB CWDM* LC SFP -40 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9380-CXX0G 2.488 Gb/s LR-2/L-16.2 >28 dB CWDM* LC SFP    0 ~ 70°C 5 to 0 dBm -28 dBm
SPS-9380B-CXX0G 2.488 Gb/s LR-2/L-16.2 >28 dB CWDM* LC SFP   -5 ~ 85°C 5 to 0 dBm -28 dBm
SPS-9380A-CXX0G 2.488 Gb/s LR-2/L-16.2 >28 dB CWDM* LC SFP -40 ~ 85°C 5 to 0 dBm -28 dBm
SPS-93100-CXX0G 2.488 Gb/s LR-2/L-16.2 >31 dB CWDM* LC SFP    0 ~ 70°C 5 to 1 dBm -30 dBm
SPS-93100B-CXX0G 2.488 Gb/s LR-2/L-16.2 >31 dB CWDM* LC SFP   -5 ~ 85°C 5 to 1 dBm -30 dBm
SPS-93100A-CXX0G 2.488 Gb/s LR-2/L-16.2 >31 dB CWDM* LC SFP -40 ~ 85°C 5 to 1 dBm -30 dBm
SPS-93120-CXX0G 2.488 Gb/s LR-2/L-16.2 >33 dB CWDM* LC SFP    0 ~ 70°C 6 to 3 dBm -30 dBm
SPS-93120B-CXX0G 2.488 Gb/s LR-2/L-16.2 >33 dB CWDM* LC SFP   -5 ~ 85°C 6 to 3 dBm -30 dBm
SPS-93120A-CXX0G 2.488 Gb/s LR-2/L-16.2 >33 dB CWDM* LC SFP -40 ~ 85°C 6 to 3 dBm -30 dBm
SPS-9340W-CXX0G 2.488 Gb/s IR-2/S-16.2 >18 dB CWDM* LC SFP with DMI    0 ~ 70°C 3 to -2 dBm -20 dBm
SPS-9340BW-CXX0G 2.488 Gb/s IR-2/S-16.2 >18 dB CWDM* LC SFP with DMI   -5 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9340AW-CXX0G 2.488 Gb/s IR-2/S-16.2 >18 dB CWDM* LC SFP with DMI -40 ~ 85°C 3 to -2 dBm -20 dBm
SPS-9380W-CXX0G 2.488 Gb/s LR-2/L-16.2 >28 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -28 dBm
SPS-9380BW-CXX0G 2.488 Gb/s LR-2/L-16.2 >28 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -28 dBm
SPS-9380AW-CXX0G 2.488 Gb/s LR-2/L-16.2 >28 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -28 dBm
SPS-93100W-CXX0G 2.488 Gb/s LR-2/L-16.2 >31 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 1 dBm -30 dBm
SPS-93100BW-CXX0G 2.488 Gb/s LR-2/L-16.2 >31 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 1 dBm -30 dBm
SPS-93100AW-CXX0G 2.488 Gb/s LR-2/L-16.2 >31 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 1 dBm -30 dBm
SPS-93120W-CXX0G 2.488 Gb/s LR-2/L-16.2 >33 dB CWDM* LC SFP with DMI    0 ~ 70°C 6 to 3 dBm -30 dBm
SPS-93120BW-CXX0G 2.488 Gb/s LR-2/L-16.2 >33 dB CWDM* LC SFP with DMI   -5 ~ 85°C 6 to 3 dBm -30 dBm
SPS-93120AW-CXX0G 2.488 Gb/s LR-2/L-16.2 >33 dB CWDM* LC SFP with DMI -40 ~ 85°C 6 to 3 dBm -30 dBm
*18 Wavelength : from 1270 nm to 1610 nm , each step 20 nm


FC(2X/1X) CWDM SFP SM LC
Product Number Bit Rate FC-PI Power Budget Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-9380F-CXX0G 2.125/1.063 Gb/s 200/100 >23 dB CWDM* LC SFP    0 ~ 70°C 5 to 0 dBm -23 dBm
SPS-9380BF-CXX0G 2.125/1.063 Gb/s 200/100 >23 dB CWDM* LC SFP   -5 ~ 85°C 5 to 0 dBm -23 dBm
SPS-9380AF-CXX0G 2.125/1.063 Gb/s 200/100 >23 dB CWDM* LC SFP -40 ~ 85°C 5 to 0 dBm -23 dBm
SPS-93120F-CXX0G 2.125/1.063 Gb/s 200/100 >30 dB CWDM* LC SFP    0 ~ 70°C 5 to 0 dBm -30 dBm
SPS-93120BF-CXX0G 2.125/1.063 Gb/s 200/100 >30 dB CWDM* LC SFP   -5 ~ 85°C 5 to 0 dBm -30 dBm
SPS-93120AF-CXX0G 2.125/1.063 Gb/s 200/100 >30 dB CWDM* LC SFP -40 ~ 85°C 5 to 0 dBm -30 dBm
SPS-9380FW-CXX0G 2.125/1.063 Gb/s 200/100 >23 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -23 dBm
SPS-9380BFW-CXX0G 2.125/1.063 Gb/s 200/100 >23 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -23 dBm
SPS-9380AFW-CXX0G 2.125/1.063 Gb/s 200/100 >23 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -23 dBm
SPS-93120FW-CXX0G 2.125/1.063 Gb/s 200/100 >30 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -30 dBm
SPS-93120BFW-CXX0G 2.125/1.063 Gb/s 200/100 >30 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -30 dBm
SPS-93120AFW-CXX0G 2.125/1.063 Gb/s 200/100 >30 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -30 dBm
**CWDM Wavelength : 18 Wavelength : from 1270 nm to 1610 nm , each step 20 nm


1.25G CWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power Budget Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-7350-CXX0G 1.25 Gb/s XD >19 dB CWDM* LC SFP    0 ~ 70°C 0 to -5dBm -24 dBm
SPS-7350B-CXX0G 1.25 Gb/s XD >19 dB CWDM* LC SFP   -5 ~ 85°C 0 to -5dBm -24 dBm
SPS-7350A-CXX0G 1.25 Gb/s XD >19 dB CWDM* LC SFP -40 ~ 85°C 0 to -5 dBm -24 dBm
SPS-7380-CXX0G 1.25 Gb/s ZX >24 dB CWDM* LC SFP    0 ~ 70°C 5 to 0 dBm -24 dBm
SPS-7380B-CXX0G 1.25 Gb/s ZX >24 dB CWDM* LC SFP   -5 ~ 85°C 5 to 0 dBm -24 dBm
SPS-7380A-CXX0G 1.25 Gb/s ZX >24 dB CWDM* LC SFP -40 ~ 85°C 5 to 0 dBm -24 dBm
SPS-7385-CXX0G 1.25 Gb/s   >27 dB CWDM* LC SFP    0 ~ 70°C 5 to 0 dBm -27 dBm
SPS-7385B-CXX0G 1.25 Gb/s   >27 dB CWDM* LC SFP   -5 ~ 85°C 5 to 0 dBm -27 dBm
SPS-7385A-CXX0G 1.25 Gb/s   >27 dB CWDM* LC SFP -40 ~ 85°C 5 to 0 dBm -27 dBm
SPS-73120-CXX0G 1.25 Gb/s   >32 dB CWDM* LC SFP    0 ~ 70°C 5 to 0 dBm -32 dBm
SPS-73120B-CXX0G 1.25 Gb/s   >32 dB CWDM* LC SFP   -5 ~ 85°C 5 to  0dBm -32 dBm
SPS-73120A-CXX0G 1.25 Gb/s   >32 dB CWDM* LC SFP -40 ~ 85°C 5 to 0 dBm -32 dBm
SPS-73160-CXX0G 1.25 Gb/s   >37 dB CWDM* LC SFP    0 ~ 70°C 5 to 1 dBm -36 dBm
SPS-73160B-CXX0G 1.25 Gb/s   >37 dB CWDM* LC SFP   -5 ~ 85°C 5 to 1 dBm -36 dBm
SPS-73160A-CXX0G 1.25 Gb/s   >37 dB CWDM* LC SFP -40 ~ 85°C 5 to 1 dBm -36 dBm
SPS-73180-CXX0G 1.25 Gb/s   >39 dB CWDM* LC SFP    0 ~ 70°C 6 to 3 dBm -36 dBm
SPS-73180B-CXX0G 1.25 Gb/s   >39 dB CWDM* LC SFP   -5 ~ 85°C 6 to 3 dBm -36 dBm
SPS-73180A-CXX0G 1.25 Gb/s   >39 dB CWDM* LC SFP -40 ~ 85°C 6 to 3 dBm -36 dBm
SPS-73200-CXX0G 1.25 Gb/s   >41 dB CWDM* LC SFP    0 ~ 70°C 8 to 5 dBm -36 dBm
SPS-73200B-CXX0G 1.25 Gb/s   >41 dB CWDM* LC SFP   -5 ~ 85°C 8 to 5 dBm -36 dBm
SPS-73200A-CXX0G 1.25 Gb/s   >41dB CWDM* LC SFP -40 ~ 85°C 8 to 5 dBm -36 dBm
SPS-7350W-CXX0G 1.25 Gb/s XD >19 dB CWDM* LC SFP with DMI    0 ~ 70°C 0 to -5 dBm -24 dBm
SPS-7350BW-CXX0G 1.25 Gb/s XD >19 dB CWDM* LC SFP with DMI   -5 ~ 85°C 0 to -5 dBm -24 dBm
SPS-7350AW-CXX0G 1.25 Gb/s XD >19 dB CWDM* LC SFP with DMI -40 ~ 85°C 0 to -5 dBm -24 dBm
SPS-7380W-CXX0G 1.25 Gb/s ZX >24 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -24 dBm
SPS-7380BW-CXX0G 1.25 Gb/s ZX >24 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -24 dBm
SPS-7380AW-CXX0G 1.25 Gb/s ZX >24 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -24 dBm
SPS-7385W-CXX0G 1.25 Gb/s   >27 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -27 dBm
SPS-7385BW-CXX0G 1.25 Gb/s   >27 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -27 dBm
SPS-7385AW-CXX0G 1.25 Gb/s   >27 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -27 dBm
SPS-73120W-CXX0G 1.25 Gb/s   >32 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -32 dBm
SPS-73120BW-CXX0G 1.25 Gb/s   >32 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -32 dBm
SPS-73120AW-CXX0G 1.25 Gb/s   >32 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -32 dBm
SPS-73160W-CXX0G 1.25 Gb/s   >37 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 1 dBm -36 dBm
SPS-73160BW-CXX0G 1.25 Gb/s   >37 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 1 dBm -36 dBm
SPS-73160AW-CXX0G 1.25 Gb/s   >37 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 1 dBm -36 dBm
SPS-73180W-CXX0G 1.25 Gb/s   >39 dB CWDM* LC SFP with DMI    0 ~ 70°C 6 to 3 dBm -36 dBm
SPS-73180BW-CXX0G 1.25 Gb/s   >39 dB CWDM* LC SFP with DMI   -5 ~ 85°C 6 to 3dBm -36 dBm
SPS-73180AW-CXX0G 1.25 Gb/s   >39 dB CWDM* LC SFP with DMI -40 ~ 85°C 6 to 3 dBm -36 dBm
SPS-73200W-CXX0G 1.25 Gb/s   >41 dB CWDM* LC SFP with DMI    0 ~ 70°C 8 to 5 dBm -36 dBm
SPS-73200BW-CXX0G 1.25 Gb/s   >41 dB CWDM* LC SFP with DMI   -5 ~ 85°C 8 to 5 dBm -36 dBm
SPS-73200AW-CXX0G 1.25 Gb/s   >41 dB CWDM* LC SFP with DMI -40 ~ 85°C 8 to 5 dBm -36 dBm
*18 Wavelength : from 1270 nm to 1610 nm , each step 20 nm


622Mb/s CWDM SFP SM LC
Product NumberBit Rate Bit Rate SONET
/SDH
Power Budget Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-5380-CXX0G 622 Mb/s   >29 dB CWDM* LC SFP    0 ~ 70°C 5 to 0 dBm -29 dBm
SPS-5380B-CXX0G 622 Mb/s   >29 dB CWDM* LC SFP   -5 ~ 85°C 5 to 0 dBm -29 dBm
SPS-5380A-CXX0G 622 Mb/s   >29 dB CWDM* LC SFP -40 ~ 85°C 5 to 0 dBm -29 dBm
SPS-53120-CXX0G 622 Mb/s   >34 dB CWDM* LC SFP    0 ~ 70°C 5 to 0 dBm -34 dBm
SPS-53120B-CXX0G 622 Mb/s   >34 dB CWDM* LC SFP   -5 ~ 85°C 5 to 0 dBm -34 dBm
SPS-53120A-CXX0G 622 Mb/s   >34 dB CWDM* LC SFP -40 ~ 85°C 5 to 0 dBm -34 dBm
SPS-53160-CXX0G 622 Mb/s   >38 dB CWDM* LC SFP    0 ~ 70°C 5 to 1 dBm -37 dBm
SPS-53160B-CXX0G 622 Mb/s   >38 dB CWDM* LC SFP   -5 ~ 85°C 5 to 1 dBm -37 dBm
SPS-53160A-CXX0G 622 Mb/s   >38 dB CWDM* LC SFP -40 ~ 85°C 5 to 1 dBm -37 dBm
SPS-53200-CXX0G 622 Mb/s   >41 dB CWDM* LC SFP    0 ~ 70°C 6 to 3 dBm -38 dBm
SPS-53200B-CXX0G 622 Mb/s   >41 dB CWDM* LC SFP   -5 ~ 85°C 6 to 3 dBm -38 dBm
SPS-53200A-CXX0G 622 Mb/s   >41 dB CWDM* LC SFP -40 ~ 85°C 6 to 3 dBm -38 dBm
SPS-5380W-CXX0G 622 Mb/s   >29 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -29 dBm
SPS-5380BW-CXX0G 622 Mb/s   >29 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -29 dBm
SPS-5380AW-CXX0G 622 Mb/s   >29 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -29 dBm
SPS-53120W-CXX0G 622 Mb/s   >34 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 0 dBm -34 dBm
SPS-53120BW-CXX0G 622 Mb/s   >34 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 0 dBm -34 dBm
SPS-53120AW-CXX0G 622 Mb/s   >34 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 0 dBm -34 dBm
SPS-53160W-CXX0G 622 Mb/s   >38 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to 1 dBm -37 dBm
SPS-53160BW-CXX0G 622 Mb/s   >38 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to 1 dBm -37 dBm
SPS-53160AW-CXX0G 622 Mb/s   >38 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to 1 dBm -37 dBm
SPS-53200W-CXX0G 622 Mb/s   >41 dB CWDM* LC SFP with DMI    0 ~ 70°C 6 to 3 dBm -38 dBm
SPS-53200BW-CXX0G 622 Mb/s   >41 dB CWDM* LC SFP with DMI   -5 ~ 85°C 6 to 3 dBm -38 dBm
SPS-53200AW-CXX0G 622 Mb/s   >41 dB CWDM* LC SFP with DMI -40 ~ 85°C 6 to 3 dBm -38 dBm
*18-Wavelength from 1270 nm to 1610 nm, each step 20 nm


155Mb/s CWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power Budget Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-3380-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP    0 ~ 70°C 0 to -5 dBm -34 dBm
SPS-3380B-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP   -5 ~ 85°C 0 to -5 dBm -34 dBm
SPS-3380A-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP -40 ~ 85°C 0 to -5 dBm -34 dBm
SPS-33100-CXX0G 125/155 Mb/s   >31 dB CWDM* LC SFP    0 ~ 70°C 2 to -3 dBm -34 dBm
SPS-33100B-CXX0G 125/155 Mb/s   >31 dB CWDM* LC SFP   -5 ~ 85°C 2 to -3 dBm -34 dBm
SPS-33100A-CXX0G 125/155 Mb/s   >31 dB CWDM* LC SFP -40 ~ 85°C 2 to -3 dBm -34 dBm
SPS-33120-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP    0 ~ 70°C 5 to  0 dBm -34 dBm
SPS-33120B-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP   -5 ~ 85°C 5 to  0 dBm -34 dBm
SPS-33120A-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP -40 ~ 85°C 5 to  0 dBm -34 dBm
SPS-33160-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP    0 ~ 70°C 5 to  2 dBm -35 dBm
SPS-33160B-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP   -5 ~ 85°C 5 to  2 dBm -35 dBm
SPS-33160A-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP -40 ~ 85°C 5 to  2 dBm -35 dBm
SPS-33200-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP    0 ~ 70°C 5 to  1 dBm -45 dBm
SPS-33200B-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP   -5 ~ 85°C 5 to  1 dBm -45 dBm
SPS-33200A-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP -40 ~ 85°C 5 to  1 dBm -45 dBm
SPS-33201-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP    0 ~ 70°C 6 to  2 dBm -45 dBm
SPS-33201B-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP   -5 ~ 85°C 6 to  2 dBm -45 dBm
SPS-33201A-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP -40 ~ 85°C 6 to  2 dBm -45 dBm
SPS-33240-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP    0 ~ 70°C 8 to  5 dBm -45 dBm
SPS-33240B-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP   -5 ~ 85°C 8 to  5 dBm -45 dBm
SPS-33240A-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP -40 ~ 85°C 8 to  5 dBm -45 dBm
SPS-3380W-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP with DMI    0 ~ 70°C 0 to -5 dBm -34 dBm
SPS-3380BW-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP with DMI   -5 ~ 85°C 0 to -5 dBm -34 dBm
SPS-3380AW-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP with DMI -40 ~ 85°C 0 to -5 dBm -34 dBm
SPS-33100W-CXX0G 125/155 Mb/s   >31dB CWDM* LC SFP with DMI    0 ~ 70°C 2 to -3 dBm -34 dBm
SPS-33100BW-CXX0G 125/155 Mb/s   >31dB CWDM* LC SFP with DMI   -5 ~ 85°C 2 to -3 dBm -34 dBm
SPS-33100AW-CXX0G 125/155 Mb/s   >31dB CWDM* LC SFP with DMI -40 ~ 85°C 2 to -3 dBm -34 dBm
SPS-33120W-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to  0 dBm -34 dBm
SPS-33120BW-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to  0 dBm -34  dBm
SPS-33120AW-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to  0 dBm -34  dBm
SPS-33160W-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to  2 dBm -35 dBm
SPS-33160BW-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to  2 dBm -35 dBm
SPS-33160AW-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to  2 dBm -35 dBm
SPS-33200W-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to  1 dBm -45 dBm
SPS-33200BW-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to   1dBm -45 dBm
SPS-33200AW-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to   1dBm -45 dBm
SPS-33201W-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP with DMI    0 ~ 70°C 6 to  2 dBm -45 dBm
SPS-33201BW-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP with DMI   -5 ~ 85°C 6 to  2 dBm -45 dBm
SPS-33201AW-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP with DMI -40 ~ 85°C 6 to  2 dBm -45 dBm
SPS-33240W-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP with DMI    0 ~ 70°C 8 to  5 dBm -45 dBm
SPS-33240BW-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP with DMI   -5 ~ 85°C 8 to  5 dBm -45 dBm
SPS-33240AW-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP with DMI -40 ~ 85°C 8 to  5 dBm -45 dBm
*18 Wavelength : from 1270 nm to 1610 nm , each step 20 nm
