100Mbps to 622Mbps

155 Mb/s CWDM

1 / 1
CWDM 1X9 SM SC/FC/ST
Product Number Bit Rate SONET
/SDH		 Power
Budget		 Wavelength Voltage Package Temperature
Range		 TX Power RX Sens. Data Sheet
TRS-3380-CXX0G 155 Mb/s LR-2/L-1.2 >29 dB CWDM* 3.3 V 1x9 SC/ST/FC   0 ~ 70°C   5 to 0 dBm -34 dBm
TRS-33100-CXX0G 155 Mb/s ELR >31 dB CWDM* 3.3 V 1x9 SC/ST/FC   0 ~ 70°C   5 to 0 dBm -34 dBm
TRS-33120-CXX0G 155 Mb/s ELR >34 dB CWDM* 3.3 V 1x9 SC/ST/FC   0 ~ 70°C   5 to 0 dBm -34 dBm
TRS-3280-CXX0G 155 Mb/s LR-2/L-1.2 >29 dB CWDM*    5 V 1x9 SC/ST/FC   0 ~ 70°C   5 to 0 dBm -34 dBm
TRS-32100-CXX0G 155 Mb/s ELR >31 dB CWDM*    5 V 1x9 SC/ST/FC   0 ~ 70°C   5 to 0 dBm -34 dBm
TRS-32120-CXX0G 155 Mb/s ELR >34 dB CWDM*    5 V 1x9 SC/ST/FC   0 ~ 70°C   5 to 1 dBm -34 dBm
*18-Wavelength from 1270 nm to 1610 nm, each step 20 nm


CWDM SFP SM LC
Product Number Bit Rate SONET
/SDH		 Power Budget Wavelength Package Temperature
Range		 TX Power RX Sens. Data
Sheet
SPS-3380-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP    0 ~ 70°C 0 to -5 dBm -34 dBm
SPS-3380B-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP   -5 ~ 85°C 0 to -5 dBm -34 dBm
SPS-3380A-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP -40 ~ 85°C 0 to -5 dBm -34 dBm
SPS-33100-CXX0G 125/155 Mb/s   >31 dB CWDM* LC SFP    0 ~ 70°C 2 to -3 dBm -34 dBm
SPS-33100B-CXX0G 125/155 Mb/s   >31 dB CWDM* LC SFP   -5 ~ 85°C 2 to -3 dBm -34 dBm
SPS-33100A-CXX0G 125/155 Mb/s   >31 dB CWDM* LC SFP -40 ~ 85°C 2 to -3 dBm -34 dBm
SPS-33120-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP    0 ~ 70°C 5 to  0 dBm -34 dBm
SPS-33120B-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP   -5 ~ 85°C 5 to  0 dBm -34 dBm
SPS-33120A-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP -40 ~ 85°C 5 to  0 dBm -34 dBm
SPS-33160-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP    0 ~ 70°C 5 to  2 dBm -35 dBm
SPS-33160B-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP   -5 ~ 85°C 5 to  2 dBm -35 dBm
SPS-33160A-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP -40 ~ 85°C 5 to  2 dBm -35 dBm
SPS-33200-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP    0 ~ 70°C 5 to  1 dBm -45 dBm
SPS-33200B-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP   -5 ~ 85°C 5 to  1 dBm -45 dBm
SPS-33200A-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP -40 ~ 85°C 5 to  1 dBm -45 dBm
SPS-33201-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP    0 ~ 70°C 6 to  2 dBm -45 dBm
SPS-33201B-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP   -5 ~ 85°C 6 to  2 dBm -45 dBm
SPS-33201A-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP -40 ~ 85°C 6 to  2 dBm -45 dBm
SPS-33240-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP    0 ~ 70°C 8 to  5 dBm -45 dBm
SPS-33240B-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP   -5 ~ 85°C 8 to  5 dBm -45 dBm
SPS-33240A-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP -40 ~ 85°C 8 to  5 dBm -45 dBm
SPS-3380W-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP with DMI    0 ~ 70°C 0 to -5 dBm -34 dBm
SPS-3380BW-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP with DMI   -5 ~ 85°C 0 to -5 dBm -34 dBm
SPS-3380AW-CXX0G 125/155 Mb/s   >29 dB CWDM* LC SFP with DMI -40 ~ 85°C 0 to -5 dBm -34 dBm
SPS-33100W-CXX0G 125/155 Mb/s   >31dB CWDM* LC SFP with DMI    0 ~ 70°C 2 to -3 dBm -34 dBm
SPS-33100BW-CXX0G 125/155 Mb/s   >31dB CWDM* LC SFP with DMI   -5 ~ 85°C 2 to -3 dBm -34 dBm
SPS-33100AW-CXX0G 125/155 Mb/s   >31dB CWDM* LC SFP with DMI -40 ~ 85°C 2 to -3 dBm -34 dBm
SPS-33120W-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to  0 dBm -34 dBm
SPS-33120BW-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to  0 dBm -34  dBm
SPS-33120AW-CXX0G 125/155 Mb/s   >34 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to  0 dBm -34  dBm
SPS-33160W-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to  2 dBm -35 dBm
SPS-33160BW-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to  2 dBm -35 dBm
SPS-33160AW-CXX0G 125/155 Mb/s   >37 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to  2 dBm -35 dBm
SPS-33200W-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP with DMI    0 ~ 70°C 5 to  1 dBm -45 dBm
SPS-33200BW-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP with DMI   -5 ~ 85°C 5 to   1dBm -45 dBm
SPS-33200AW-CXX0G 125/155 Mb/s   >46 dB CWDM* LC SFP with DMI -40 ~ 85°C 5 to   1dBm -45 dBm
SPS-33201W-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP with DMI    0 ~ 70°C 6 to  2 dBm -45 dBm
SPS-33201BW-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP with DMI   -5 ~ 85°C 6 to  2 dBm -45 dBm
SPS-33201AW-CXX0G 125/155 Mb/s   >47 dB CWDM* LC SFP with DMI -40 ~ 85°C 6 to  2 dBm -45 dBm
SPS-33240W-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP with DMI    0 ~ 70°C 8 to  5 dBm -45 dBm
SPS-33240BW-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP with DMI   -5 ~ 85°C 8 to  5 dBm -45 dBm ​
SPS-33240AW-CXX0G 125/155 Mb/s   >50 dB CWDM* LC SFP with DMI -40 ~ 85°C 8 to  5 dBm -45 dBm
*18 Wavelength : from 1270 nm to 1610 nm , each step 20 nm


CWDM SFF SM LC
Product Number Bit Rate SONET
/SDH		 Power
Budget		 Wavelength Package Temperature
Range		 TX Power RX Sens. Data Sheet
TRSL-3380-CXX0G 125/155 Mb/s   >29 dB CWDM* 2x5 LC   0 ~ 70°C 0 to -5 dBm -34 dBm
TRSL-33100-CXX0G 125/155 Mb/s   >31 dB CWDM* 2x5 LC   0 ~ 70°C 2 to -3 dBm -34 dBm
TRSL-33120-CXX0G 125/155 Mb/s   >34 dB CWDM* 2x5 LC   0 ~ 70°C 5 to  0 dBm -34 dBm
TRSL-3380W-CXX0G 125/155 Mb/s   >29 dB CWDM* 2x10 LC   0 ~ 70°C 0 to -5 dBm -34 dBm
TRSL-33100W-CXX0G 125/155 Mb/s   >31 dB CWDM* 2x10 LC   0 ~ 70°C 2 to -3 dBm -34 dBm
TRSL-33120W-CXX0G 125/155 Mb/s   >34 dB CWDM* 2x10 LC   0 ~ 70°C 5 to  0 dBm -34 dBm
CWDM*: 18-Wavelength from 1270 nm to 1610 nm, each step 20 nm
