PRODUCTS
2-Fiber SFP/SFP+

DWDM

32GFC SFP28 SM LC DWDM
Product Number FC Reach Spacing Wavelength Package Temperature
Range
Data
Sheet
SPS-2511FW-DXXG* 32/16/8 G 10km 100GHz DWDM SFP28 with DMI    0 ~ 70°C


25GE SFP28 SM LC DWDM
Product Number FC Reach Spacing Wavelength Package Temperature
Range
Data
Sheet
SPS-2511W-DXXG* 25 G 10km 100GHz DWDM SFP28 with DMI    0 ~ 70°C
SPS-2511BW-DXXG* 25 G 10km 100GHz DWDM SFP28 with DMI -10 ~ 85°C
SPS-2511AW-DXXG* 25 G 10km 100GHz DWDM SFP28 with DMI -40 ~ 85°C


16GFC SFP+ SM LC DWDM
Product Number FC Reach Spacing Wavelength Package Temperature
Range
Data
Sheet
SPS-6341W-DXXG* 16/8/4 G 40km 100GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-6345W-DXXXG* 16/8/4 G 40km 50GHz DWDM SFP+ with DMI    0 ~ 70°C
*RX with rate selected CDR


10Gb/s DWDM SFP+ SM LC
Product Number Bit Rate 10GBASE Reach Spacing Wavelength Package Temperature
Range
Data
Sheet
SPS-2341W-DXXG 10.3 Gb/s ER/EW 40 km 100GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-2341BW-DXXG 10.3 Gb/s ER/EW 40 km 100GHz DWDM SFP+ with DMI   -5 ~ 85°C
SPS-2341AW-DXXG 10.3 Gb/s ER/EW 40 km 100GHz DWDM SFP+ with DMI  -40 ~ 85°C
SPS-2381W-DXXG 9.95 ~10.52 Gb/s ZR/ZW 80km 100GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-2381BW-DXXG 9.95 ~10.52 Gb/s ZR/ZW 80km 100GHz DWDM SFP+ with DMI   -5 ~ 85°C
SPS-2381AW-DXXG 9.95 ~10.52 Gb/s ZR/ZW 80km 100GHz DWDM SFP+ with DMI   -40 ~ 85°C
SPS-2341MW-DXXG 9.95 ~11.1 Gb/s Multirate* 40km 100GHz DWDM SFP+ with DMI      0 ~ 70°C
SPS-2341BMW-DXXG 9.95 ~11.1 Gb/s Multirate* 40km 100GHz DWDM SFP+ with DMI   -5 ~ 85°C
SPS-2341AMW-DXXG 9.95 ~11.1 Gb/s Multirate* 40km 100GHz DWDM SFP+ with DMI   -40 ~ 85°C
SPS-2381MW-DXXG 9.95 ~11.1 Gb/s Multirate* 80km 100GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-2381BMW-DXXG 9.95 ~11.1 Gb/s Multirate* 80km 100GHz DWDM SFP+ with DMI -5 ~ 85°C
SPS-2381AMW-DXXG 9.95 ~11.1 Gb/s Multirate* 80km 100GHz DWDM SFP+ with DMI -40 ~ 85°C
SPS-2345W-DXXXG 10.3 Gb/s ER/EW 40km 50GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-2345BW-DXXXG 10.3 Gb/s ER/EW 40km 50GHz DWDM SFP+ with DMI -5 ~ 85°C
SPS-2345AW-DXXXG 10.3 Gb/s ER/EW 40km 50GHz DWDM SFP+ with DMI -40 ~ 85°C
SPS-2385W-DXXXG 9.95 ~10.52 Gb/s ZR/ZW* 80km 50GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-2345MW-DXXXG 9.95 ~11.1 Gb/s Multirate* 40km 50GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-2385MW-DXXXG 9.95 ~11.1 Gb/s Multirate* 80km 50GHz DWDM SFP+ with DMI    0 ~ 70°C
*SONET OC-192 LR2, 10GBASE-ZR/ZW, 10G Fibre Channel, ITU-T G.709, 10GBASE-ZR/ZW + FEC


8Gb/s DWDM SFP+ SM LC
Product Number Bit Rate FC Reach Spacing Wavelength Package Temperature
Range
Data
Sheet
SPS-4341W-DXXG 8.5 Gb/s 8G/4G/2G 40 km 100GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-4381W-DXXG 8.5 Gb/s 8G/4G/2G 80km 100GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-4345W-DXXXG 8.5 Gb/s 8G/4G/2G 40km 50GHz DWDM SFP+ with DMI    0 ~ 70°C
SPS-4385W-DXXXG 8.5 Gb/s 8G/4G/2G 80km 50GHz DWDM SFP+ with DMI    0 ~ 70°C


6Gb/s DWDM SFP+ SM LC
Product Number Bit Rate Power Budget Spacing Wavelength Package Temperature
Range
Data
Sheet
SPS-4341RW-DXXG 1 ~ 6.25 Gb/s >14dB 100GHz DWDM* SFP+ with DMI    0 ~ 70°C
SPS-4381RW-DXXG 1 ~ 6.25 Gb/s >23dB 100GHz DWDM* SFP+ with DMI    0 ~ 70°C
*100GHz ITU Grid wavelength


DWDM SFP SM LC
Product Number Bit Rate FC-PI Power
Budget
Spacing / Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-8350W-DXXG 4/2/1 Gb/s 400/200/100 >20dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  5 to 2dBm -18dBm
SPS-8380W-DXXG 4/2/1 Gb/s 400/200/100 >26dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  5 to 0dBm -26dBm
SPS-83120W-DXXG 4/2/1 Gb/s 400/200/100 >26dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  7 to 4dBm -26dBm


Multi-rate (3.2Gb/s) DWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power
Budget
Spacing / Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-9350RW-DXXG Multi-rate*   >20dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  5 to 2dBm -18dBm
SPS-9380RW-DXXG Multi-rate*   >28dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  5 to 0dBm -28dBm
SPS-93120RW-DXXG Multi-rate*   >32dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  7 to 4dBm -28dBm
*3.185Gb/s,3.125Gb/s, 2.67Gb/s / OC-48 / 2X FC / GbE / 1X FC / OC-12 / OC-3


Multi-rate (2.67Gb/s) DWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power
Budget
Spacing / Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-9350MW-DXXG Multi-rate* LR-2/L-16.2 >20dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  5 to 2dBm -18dBm
SPS-9380MW-DXXG Multi-rate*   >28dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  5 to 0dBm -28dBm
SPS-93120MW-DXXG Multi-rate*   >32dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  7 to 4dBm -28dBm
SPS-93160MW-DXXG Multi-rate*   >35dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  8 to 5dBm -30dBm
*  2.67Gb/s / OC-48 / 2X FC / GbE / 1X FC / OC-12 / OC-3 / FE



2.5 Gb/s DWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power
Budget
Spacing / Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-9350W-DXXG 2.488 Gb/s LR-2/L-16.2 >20dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  5 to 2dBm -18dBm
SPS-9380W-DXXG 2.488 Gb/s   >28dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  5 to 0dBm -28dBm
SPS-93120W-DXXG 2.488 Gb/s   >32dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  7 to 4dBm -28dBm
SPS-93160W-DXXG 2.488 Gb/s   >35dB 100GHz / DWDM SFP with DMI   0 ~ 70°C  8 to 5dBm -30dBm


Gigabit Ethernet DWDM SFP SM LC
Product Number Bit Rate 1000
BASE
Power Budget Spacing / Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-7350W-DXXG 1.25 Gb/s XD >19dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 0 to -5dBm -24dBm
SPS-7380W-DXXG 1.25 Gb/s ZX >26dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 5 to 2dBm -24dBm
SPS-73120W-DXXG 1.25 Gb/s   >32dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 5 to 0dBm -32dBm
SPS-73160W-DXXG 1.25 Gb/s   >37dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 5 to 2dBm -35dBm
SPS-73180W-DXXG 1.25 Gb/s   >39dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 7 to 4dBm -35dBm
SPS-73200W-DXXG 1.25 Gb/s   >41dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 8 to 5dBm -36dBm


622 Mb/s DWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power Budget Spacing / Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-5380W-DXXG 622 Mb/s LR-2/L-4.2 >29dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 5 to 0dBm -29dBm
SPS-53120W-DXXG 622 Mb/s   >34dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 5 to 0dBm -34dBm
SPS-53160W-DXXG 622 Mb/s   >39dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 5 to 2dBm -37dBm
SPS-53200W-DXXG 622 Mb/s   >42dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 7 to 4dBm -38dBm


155Mb/s DWDM SFP SM LC
Product Number Bit Rate SONET
/SDH
Power Budget Spacing / Wavelength Package Temperature
Range
TX Power RX Sens. Data
Sheet
SPS-3380W-DXXG 125/155 Mb/s LR-2/L-1.2 >29dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 0 to -5dBm -34dBm
SPS-33120W-DXXG 125/155 Mb/s   >34dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 5 to 0dBm -34dBm
SPS-33160W-DXXG 125/155 Mb/s   >37dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 5 to 2dBm -35dBm
SPS-332000W-DXXG 125/155 Mb/s   >47dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 5 to 2dBm -45dBm
SPS-33240W-DXXG 125/155 Mb/s   >50dB 100GHz with DWDM SFP with DMI   0 ~ 70°C 8 to 5dBm -45dBm
